VOLKSWAGEN T-CROSS ESTATE

Emissions - ICE

• HC+NOx
  Not Available
• Particles
  Not Available
• Standard Emissions
  EURO 6
• WLTP - CO2 (g/km) - Comb
  126
• WLTP - CO2 (g/km) - Comb - TEH
  131
• WLTP - CO2 (g/km) - Comb - TEL
  126

Engine and Drive Train

• Camshaft
  DOHC
• Catalytic Convertor
  Yes
• CC
  999
• Compression Ratio
  11.5:1
• Cylinder Layout
  IN-LINE
• Cylinders
  3
• Cylinders - Bore (mm)
  74.5
• Cylinders - Stroke (mm)
  76.4
• Engine Code
  D313BX
• Engine Layout
  FRONT TRANSVERSE
• Fuel Delivery
  TURBO DIRECT INJECTION
• Gears
  6 SPEED
• Number of Valves
  12
• Transmission
  MANUAL

Fuel Consumption - ICE

• EC Directive 1999/100/EC Applies
  No
• WLTP - FC (l/100km) - Comb - TEH
  5.8
• WLTP - FC (l/100km) - Comb - TEL
  5.6
• WLTP - FC (l/100km) - Extra High - TEH
  6
• WLTP - FC (l/100km) - Extra High - TEL
  5.8
• WLTP - FC (l/100km) - High - TEH
  5
• WLTP - FC (l/100km) - High - TEL
  4.8
• WLTP - FC (l/100km) - Low - TEH
  7.2
• WLTP - FC (l/100km) - Low - TEL
  7
• WLTP - FC (l/100km) - Medium - TEH
  5.6
• WLTP - FC (l/100km) - Medium - TEL
  5.4
• WLTP - MPG - Comb - TEH
  48.7
• WLTP - MPG - Comb - TEL
  50.4
• WLTP - MPG - Extra High - TEH
  47.1
• WLTP - MPG - Extra High - TEL
  48.7
• WLTP - MPG - High - TEH
  56.5
• WLTP - MPG - High - TEL
  58.9
• WLTP - MPG - Low - TEH
  39.2
• WLTP - MPG - Low - TEL
  40.4
• WLTP - MPG - Medium - TEH
  50.4
• WLTP - MPG - Medium - TEL
  52.3

General

• Alternative Fuel Qualifying
  No
• Badge Engine CC
  1.0
• Badge Power
  115
• Based On ID
  Not Available
• Coin Description
  TSI 115
• Coin Series
  Match
• Generation Mark
  1
• Insurance Group 1 - 50 Effective January 07
  14E
• Manufacturers Corrosion Perforation Guarantee - Years
  12
• Manufacturers Paintwork Guarantee - Years
  3
• NCAP Adult Occupant Protection %
  74
• NCAP Child Occupant Protection %
  81
• NCAP Overall Rating - Effective February 09
  3
• NCAP Pedestrian Protection %
  60
• NCAP Safety Assist %
  57
• Did at least one aspect of this vehicle's safety give cause for concern?
  No
• Service Interval Frequency - Months
  12
• Service Interval Mileage
  9300
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  60000
• Standard manufacturers warranty - Years
  3
• Timing Belt Interval Frequency - Months
  Not Available
• Timing Belt Interval Mileage
  Not Available
• Vehicle Homologation Class
  M1

Performance

• 0 to 62 mph (secs)
  10.1
• Engine Power - BHP
  115
• Engine Power - KW
  85
• Engine Torque - LBS.FT
  148
• Engine Torque - MKG
  20.4
• Engine Torque - NM
  200
• Engine Torque - RPM
  2000
• Top Speed
  120

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  RDE 2

Tyres

• Alloys?
  Yes
• Space Saver?
  No
• Tyre Size Front
  205/55 R17
• Tyre Size Rear
  205/55 R17
• Tyre Size Spare
  TYRE REPAIR KIT
• Wheel Style
  CLAYTON
• Wheel Type
  17" ALLOY

Vehicle Dimensions

• Height
  1573
• Height (including roof rails)
  1584
• Length
  4127
• Wheelbase
  2551
• Width
  1760
• Width (including mirrors)
  1993

Weight and Capacities

• Fuel Tank Capacity (Litres)
  40
• Gross Vehicle Weight
  1750
• Luggage Capacity (Seats Down)
  1281
• Luggage Capacity (Seats Up)
  455
• Max. Loading Weight
  549
• Max. Roof Load
  75
• Max. Towing Weight - Braked
  1100
• Max. Towing Weight - Unbraked
  630
• Minimum Kerbweight
  1201
• No. of Seats
  5
• Turning Circle - Kerb to Kerb
  10.7
