OMODA 5 ESTATE

Electric Vehicle Data

• Battery Capacity in kWh
  1.83
• Battery Type
  Lithium-ion

Emissions - ICE

• HC+NOx
  Not Available
• Particles
  Not Available
• Standard Emissions
  EURO 6
• WLTP - CO2 (g/km) - Comb
  120

Engine and Drive Train

• Camshaft
  DOHC
• Catalytic Convertor
  Yes
• CC
  1499
• Compression Ratio
  14.5:1
• Cylinder Layout
  IN-LINE
• Cylinders
  4
• Cylinders - Bore (mm)
  72
• Cylinders - Stroke (mm)
  92
• Engine Code
  KPTZ220YMDA0
• Engine Layout
  FRONT TRANSVERSE
• Fuel Delivery
  TURBO DIRECT INJECTION
• Gears
  1 SPEED
• Number of Valves
  16
• Transmission
  AUTO

Fuel Consumption - ICE

• EC Combined (mpg)
  Not Available
• EC Directive 1999/100/EC Applies
  No
• EC Extra Urban (mpg)
  Not Available
• EC Urban (mpg)
  Not Available
• WLTP - FC (l/100km) - Comb
  5.5
• WLTP - FC (l/100km) - Extra High
  6.6
• WLTP - FC (l/100km) - High
  4.9
• WLTP - FC (l/100km) - Low
  5.5
• WLTP - FC (l/100km) - Medium
  4.4
• WLTP - MPG - Comb
  51.4
• WLTP - MPG - Extra High
  43.2
• WLTP - MPG - High
  58.2
• WLTP - MPG - Low
  52.6
• WLTP - MPG - Medium
  64.6

General

• Alternative Fuel Qualifying
  Yes
• Badge Engine CC
  1.5
• Badge Power
  224
• Based On ID
  Not Available
• Coin Description
  T SHS-H
• Coin Series
  Knight
• Generation Mark
  1
• Insurance Group 1 - 50 Effective January 07
  30U
• NCAP Adult Occupant Protection %
  87
• NCAP Child Occupant Protection %
  87
• NCAP Overall Rating - Effective February 09
  5
• NCAP Pedestrian Protection %
  68
• NCAP Safety Assist %
  88
• Did at least one aspect of this vehicle's safety give cause for concern?
  No
• Service Interval Frequency - Months
  12
• Service Interval Mileage
  10000
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  100000
• Standard manufacturers warranty - Years
  7
• Vehicle Homologation Class
  M1

Performance

• 0 to 62 mph (secs)
  7.9
• Engine Power - BHP
  224
• Engine Power - KW
  165
• Engine Torque - LBS.FT
  218
• Engine Torque - MKG
  30.1
• Engine Torque - NM
  295
• Engine Torque - RPM
  2000
• Top Speed
  109

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  RDE 2

Tyres

• Alloys?
  Yes
• Space Saver?
  No
• Tyre Size Front
  215/55 R18
• Tyre Size Rear
  215/55 R18
• Tyre Size Spare
  SELF-SEALING TYRES
• Wheel Style
  Not Available
• Wheel Type
  18" ALLOY

Vehicle Dimensions

• Height
  1588
• Height (including roof rails)
  Not Available
• Length
  4447
• Wheelbase
  2610
• Width
  1824
• Width (including mirrors)
  2102

Weight and Capacities

• Fuel Tank Capacity (Litres)
  51
• Gross Vehicle Weight
  2052
• Luggage Capacity (Seats Up)
  370
• Max. Loading Weight
  506
• Max. Towing Weight - Unbraked
  750
• Minimum Kerbweight
  1546
• No. of Seats
  5
