MAZDA CX-60 ESTATE

Electric Vehicle Data

• Battery Capacity % guaranteed under warranty
  Not Available
• Battery Capacity in kWh
  17.8
• Battery Charging Scenario 1 - Charge Time (Mins)
  474
• Battery Charging Scenario 1 - Percentage Change
  0-100
• Battery Charging Scenario 1 - Power Supply - kW
  2.4
• Battery Charging Scenario 2 - Charge Time (Mins)
  288
• Battery Charging Scenario 2 - Percentage Change
  20-80
• Battery Charging Scenario 2 - Power Supply - kW
  2.4
• Battery Charging Scenario 3 - Charge Time (Mins)
  144
• Battery Charging Scenario 3 - Percentage Change
  0-100
• Battery Charging Scenario 3 - Power Supply - kW
  7.2
• Battery Charging Scenario 4 - Charge Time (Mins)
  90
• Battery Charging Scenario 4 - Percentage Change
  20-80
• Battery Charging Scenario 4 - Power Supply - kW
  7.2
• Battery Leased
  No
• Battery Type
  Lithium-ion
• Charging Port Location
  Right Side Rear
• Coupler/Connector Type
  Type 2
• Maximum Charging Rate - kW
  7.2
• Standard manufacturers Battery warranty - Mileage
  100000
• Standard manufacturers Battery warranty - Years
  8
• Usable Battery Capacity
  17.8
• WLTP - EC AC Weighted (kWh/100km) - Comb
  23
• WLTP - EC AC Weighted (miles/kWh) - Comb
  2.7
• WLTP - Equivalent AER (km) - Comb
  63
• WLTP - Equivalent AER (km) - Comb - TEH
  63
• WLTP - Equivalent AER (km) - Comb - TEL
  64
• WLTP - Equivalent AER (miles) - Comb
  39.6
• WLTP - Equivalent AER (miles) - Comb - TEH
  39.2
• WLTP - Equivalent AER (miles) - Comb - TEL
  39.8

Emissions - ICE

• HC+NOx
  Not Available
• Particles
  Not Available
• Standard Emissions
  EURO 6

Emissions - PHEV

• WLTP - CO2 Weighted (g/km) - Comb
  33
• WLTP - CO2 Weighted (g/km) - Comb - TEH
  33
• WLTP - CO2 Weighted (g/km) - Comb - TEL
  32

Engine and Drive Train

• Camshaft
  DOHC
• Catalytic Convertor
  Yes
• CC
  2488
• Compression Ratio
  13.0:1
• Cylinder Layout
  IN-LINE
• Cylinders
  4
• Cylinders - Bore (mm)
  89
• Cylinders - Stroke (mm)
  100
• Engine Layout
  FRONT TRANSVERSE
• Fuel Delivery
  MULTI POINT FUEL INJECTION
• Gears
  8 SPEED
• Number of Valves
  16
• Transmission
  AUTO

Fuel Consumption - ICE

• EC Directive 1999/100/EC Applies
  No

Fuel Consumption - PHEV

• WLTP - FC Ch Sus (l/100km) - Comb
  7.8
• WLTP - FC Ch Sus (l/100km) - Comb - TEH
  7.8
• WLTP - FC Ch Sus (l/100km) - Comb - TEL
  7.7
• WLTP - FC Ch Sus (l/100km) - Extra High
  8.2
• WLTP - FC Ch Sus (l/100km) - High
  7.2
• WLTP - FC Ch Sus (l/100km) - High - TEH
  7.2
• WLTP - FC Ch Sus (l/100km) - High - TEL
  7
• WLTP - FC Ch Sus (l/100km) - Low
  9
• WLTP - FC Ch Sus (l/100km) - Low - TEH
  9.3
• WLTP - FC Ch Sus (l/100km) - Low - TEL
  9
• WLTP - FC Ch Sus (l/100km) - Medium
  7.2
• WLTP - FC Ch Sus (l/100km) - Medium - TEH
  7.4
• WLTP - FC Ch Sus (l/100km) - Medium - TEL
  7.3
• WLTP - FC Ch Sus (mpg) - Comb
  36.2
• WLTP - FC Ch Sus (mpg) - Comb - TEH
  36.2
• WLTP - FC Ch Sus (mpg) - Comb - TEL
  36.7
• WLTP - FC Ch Sus (mpg) - Extra High
  34.4
• WLTP - FC Ch Sus (mpg) - High
  39.2
• WLTP - FC Ch Sus (mpg) - High - TEH
  39.2
• WLTP - FC Ch Sus (mpg) - High - TEL
  40.4
• WLTP - FC Ch Sus (mpg) - Low
  31.4
• WLTP - FC Ch Sus (mpg) - Low - TEH
  30.4
• WLTP - FC Ch Sus (mpg) - Low - TEL
  31.4
• WLTP - FC Ch Sus (mpg) - Medium
  39.2
• WLTP - FC Ch Sus (mpg) - Medium - TEH
  38.2
• WLTP - FC Ch Sus (mpg) - Medium - TEL
  38.7
• WLTP - FC Weighted (l/100km) - Comb
  1.5
• WLTP - FC Weighted (l/100km) - Comb - TEH
  1.5
• WLTP - FC Weighted (l/100km) - Comb - TEL
  1.4
• WLTP - FC Weighted (mpg) - Comb
  188.3
• WLTP - FC Weighted (mpg) - Comb - TEH
  188.3
• WLTP - FC Weighted (mpg) - Comb - TEL
  201.8

General

• Alternative Fuel Qualifying
  Yes
• Badge Engine CC
  2.5
• Badge Power
  327
• Based On ID
  Not Available
• Coin Description
  PHEV
• Coin Series
  Homura Plus
• Generation Mark
  1
• Insurance Group 1 - 50 Effective January 07
  39A
• NCAP Adult Occupant Protection %
  88
• NCAP Child Occupant Protection %
  91
• NCAP Overall Rating - Effective February 09
  5
• NCAP Pedestrian Protection %
  89
• NCAP Safety Assist %
  76
• Did at least one aspect of this vehicle's safety give cause for concern?
  No
• Service Interval Frequency - Months
  12
• Service Interval Mileage
  12500
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  100000
• Standard manufacturers warranty - Years
  6
• Vehicle Homologation Class
  M1

Performance

• 0 to 62 mph (secs)
  5.8
• Engine Power - BHP
  327
• Engine Power - KW
  241
• Engine Power - RPM
  6000
• Engine Torque - LBS.FT
  369
• Engine Torque - MKG
  51
• Engine Torque - NM
  500
• Engine Torque - RPM
  4000
• Top Speed
  124

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  RDE 2

Tyres

• Alloys?
  Yes
• Space Saver?
  No
• Tyre Size Front
  235/50 R20
• Tyre Size Rear
  235/50 R20
• Tyre Size Spare
  TYRE REPAIR KIT
• Wheel Style
  Black
• Wheel Type
  20" ALLOY

Vehicle Dimensions

• Height
  1680
• Length
  4745
• Wheelbase
  2870
• Width
  1890
• Width (including mirrors)
  2134

Weight and Capacities

• Fuel Tank Capacity (Litres)
  50
• Gross Vehicle Weight
  2667
• Luggage Capacity (Seats Down)
  1726
• Luggage Capacity (Seats Up)
  570
• Max. Loading Weight
  675
• Max. Roof Load
  100
• Max. Towing Weight - Braked
  2500
• Minimum Kerbweight
  1992
• No. of Seats
  5
• Turning Circle - Kerb to Kerb
  11.8
