KIA STONIC ESTATE

Emissions - ICE

• CO
  0.089
• HC
  0.024
• HC+NOx
  Not Available
• Noise Level dB(A)
  70
• NOx
  0.018
• Particles
  0.0001
• Standard Emissions
  EURO 6
• WLTP - CO2 (g/km) - Comb
  129

Engine and Drive Train

• Camshaft
  DOHC
• Catalytic Convertor
  Yes
• CC
  998
• Compression Ratio
  10.0:1
• Cylinder Layout
  IN-LINE
• Cylinders
  3
• Cylinders - Bore (mm)
  71
• Cylinders - Stroke (mm)
  84
• Engine Layout
  FRONT TRANSVERSE
• Fuel Delivery
  TURBO INJECTION
• Gears
  7 SPEED
• Number of Valves
  12
• Transmission
  AUTO

Fuel Consumption - ICE

• EC Directive 1999/100/EC Applies
  No
• WLTP - FC (l/100km) - Comb
  5.7
• WLTP - FC (l/100km) - Extra High
  6.2
• WLTP - FC (l/100km) - High
  4.8
• WLTP - FC (l/100km) - Low
  6.9
• WLTP - FC (l/100km) - Medium
  5.3
• WLTP - MPG - Comb
  49.6
• WLTP - MPG - Extra High
  45.6
• WLTP - MPG - High
  58.9
• WLTP - MPG - Low
  40.9
• WLTP - MPG - Medium
  53.3

General

• Alternative Fuel Qualifying
  Yes
• Badge Engine CC
  1.0
• Badge Power
  98
• Based On ID
  Not Available
• Coin Description
  T-GDi 48V
• Coin Series
  GT-Line S
• Generation Mark
  1
• Insurance Group 1 - 50 Effective January 07
  9E
• Manufacturers Corrosion Perforation Guarantee - Years
  12
• Manufacturers Paintwork Guarantee - Years
  5
• NCAP Adult Occupant Protection %
  Not Available
• NCAP Child Occupant Protection %
  Not Available
• NCAP Overall Rating - Effective February 09
  Not Available
• NCAP Pedestrian Protection %
  Not Available
• NCAP Safety Assist %
  Not Available
• Did at least one aspect of this vehicle's safety give cause for concern?
  No
• Service Interval Frequency - Months
  12
• Service Interval Mileage
  10000
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  100000
• Standard manufacturers warranty - Years
  7
• Timing Belt Interval Frequency - Months
  Not Available
• Timing Belt Interval Mileage
  Not Available
• Vehicle Homologation Class
  M1

Performance

• 0 to 62 mph (secs)
  12.4
• Engine Power - BHP
  98
• Engine Power - KW
  73
• Engine Power - RPM
  6000
• Engine Torque - LBS.FT
  148
• Engine Torque - MKG
  20.4
• Engine Torque - NM
  200
• Engine Torque - RPM
  2500
• Top Speed
  109

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  RDE 2

Tyres

• Alloys?
  Yes
• Space Saver?
  No
• Tyre Size Front
  205/55 R17
• Tyre Size Rear
  205/55 R17
• Tyre Size Spare
  TYRE REPAIR KIT
• Wheel Style
  Not Available
• Wheel Type
  17" ALLOY

Vehicle Dimensions

• Height
  1505
• Height (including roof rails)
  1520
• Length
  4140
• Wheelbase
  2580
• Width
  1760
• Width (including mirrors)
  Not Available

Weight and Capacities

• Fuel Tank Capacity (Litres)
  45
• Gross Vehicle Weight
  1710
• Luggage Capacity (Seats Down)
  1155
• Luggage Capacity (Seats Up)
  352
• Max. Loading Weight
  450
• Max. Towing Weight - Braked
  710
• Minimum Kerbweight
  1260
• No. of Seats
  5
• Turning Circle - Kerb to Kerb
  10.2
