HYUNDAI TUCSON ESTATE

Electric Vehicle Data

• Battery Capacity in kWh
  1.5
• Battery Type
  Lithium-ion

Emissions - ICE

• HC+NOx
  Not Available
• Particles
  Not Available
• Standard Emissions
  EURO 6
• WLTP - CO2 (g/km) - Comb
  129
• WLTP - CO2 (g/km) - Comb - TEH
  137
• WLTP - CO2 (g/km) - Comb - TEL
  127
• WLTP - CO2 (g/km) - Extra High
  169
• WLTP - CO2 (g/km) - High
  121
• WLTP - CO2 (g/km) - Low
  107
• WLTP - CO2 (g/km) - Medium
  85

Engine and Drive Train

• Camshaft
  DOHC
• Catalytic Convertor
  Yes
• CC
  1598
• Compression Ratio
  10.5:1
• Cylinder Layout
  IN-LINE
• Cylinders
  4
• Cylinders - Bore (mm)
  75.6
• Cylinders - Stroke (mm)
  89
• Engine Layout
  FRONT TRANSVERSE
• Fuel Delivery
  TURBO DIRECT INJECTION
• Gears
  6 SPEED
• Number of Valves
  16
• Transmission
  SEMI-AUTO

Fuel Consumption - ICE

• WLTP - FC (l/100km) - Comb
  5.7
• WLTP - FC (l/100km) - Extra High
  7.5
• WLTP - FC (l/100km) - High
  5.3
• WLTP - FC (l/100km) - Low
  4.7
• WLTP - FC (l/100km) - Medium
  3.8
• WLTP - MPG - Comb
  49.6
• WLTP - MPG - Extra High
  37.7
• WLTP - MPG - High
  53.3
• WLTP - MPG - Low
  60.1
• WLTP - MPG - Medium
  74.3

General

• Alternative Fuel Qualifying
  Yes
• Badge Engine CC
  1.6
• Badge Power
  215
• Based On ID
  Not Available
• Coin Description
  T Hybrid
• Coin Series
  Advance
• Generation Mark
  4
• Insurance Group 1 - 50 Effective January 07
  20E
• Manufacturers Corrosion Perforation Guarantee - Years
  12
• Did at least one aspect of this vehicle's safety give cause for concern?
  No
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  Unlimited
• Standard manufacturers warranty - Years
  5
• Vehicle Homologation Class
  M1

Performance

• 0 to 62 mph (secs)
  8.2
• Engine Power - BHP
  215
• Engine Power - KW
  158
• Engine Power - RPM
  5500
• Engine Torque - LBS.FT
  195
• Engine Torque - MKG
  26.9
• Engine Torque - NM
  264
• Engine Torque - RPM
  1500
• Top Speed
  116

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  RDE 2

Tyres

• Alloys?
  Yes
• Space Saver?
  No
• Tyre Size Front
  215/65 R17
• Tyre Size Rear
  215/65 R17
• Tyre Size Spare
  TYRE REPAIR KIT
• Wheel Style
  Not Available
• Wheel Type
  17" ALLOY

Vehicle Dimensions

• Height (including roof rails)
  1650
• Length
  4510
• Wheelbase
  2680
• Width
  1865

Weight and Capacities

• Fuel Tank Capacity (Litres)
  52
• Gross Vehicle Weight
  2190
• Luggage Capacity (Seats Down)
  1795
• Luggage Capacity (Seats Up)
  616
• Max. Loading Weight
  489
• Max. Roof Load
  100
• Max. Towing Weight - Braked
  1360
• Max. Towing Weight - Unbraked
  750
• Minimum Kerbweight
  1701
• No. of Seats
  5
• Turning Circle - Kerb to Kerb
  11
