FORD GRAND TOURNEO CONNECT ESTATE

Electric Vehicle Data

• Battery Capacity % guaranteed under warranty
  70
• Battery Capacity in kWh
  25.7
• Battery Charging Scenario 1 - Charge Time (Mins)
  230
• Battery Charging Scenario 1 - Percentage Change
  0-100
• Battery Charging Scenario 1 - Power Supply - kW
  7.2
• Battery Charging Scenario 2 - Charge Time (Mins)
  140
• Battery Charging Scenario 2 - Percentage Change
  0-100
• Battery Charging Scenario 2 - Power Supply - kW
  11
• Battery Charging Scenario 3 - Charge Time (Mins)
  26
• Battery Charging Scenario 3 - Percentage Change
  5-80
• Battery Charging Scenario 3 - Power Supply - kW
  40
• Battery Charging Scenario 4 - Charge Time (Mins)
  Not Available
• Battery Charging Scenario 4 - Percentage Change
  Not Available
• Battery Charging Scenario 4 - Power Supply - kW
  Not Available
• Battery Leased
  No
• Battery Type
  Lithium-ion
• Charging Port Location
  Left Side Front
• Coupler/Connector Type
  Type 2
• Maximum Charging Rate - kW
  40
• Standard manufacturers Battery warranty - Mileage
  100000
• Standard manufacturers Battery warranty - Years
  8
• Usable Battery Capacity
  19.7
• WLTP - EC AC Weighted (kWh/100km) - Comb
  19.6
• WLTP - EC AC Weighted (miles/kWh) - Comb
  3.2
• WLTP - Equivalent AER (km) - Comb
  114
• WLTP - Equivalent AER (miles) - Comb
  70.6

Emissions - ICE

• HC+NOx
  Not Available
• Particles
  Not Available
• Standard Emissions
  EURO 6e-bis

Emissions - PHEV

• WLTP - CO2 Weighted (g/km) - Comb
  43

Engine and Drive Train

• Camshaft
  DOHC
• Catalytic Convertor
  Yes
• CC
  1498
• Cylinder Layout
  IN-LINE
• Cylinders
  4
• Engine Layout
  FRONT TRANSVERSE
• Fuel Delivery
  TURBO INJECTION
• Gears
  6 SPEED
• Number of Valves
  16
• Transmission
  AUTO

Fuel Consumption - ICE

• EC Directive 1999/100/EC Applies
  No

Fuel Consumption - PHEV

• WLTP - FC Weighted (l/100km) - Comb
  1.9
• WLTP - FC Weighted (mpg) - Comb
  148.4

General

• Alternative Fuel Qualifying
  No
• Badge Engine CC
  1.5
• Badge Power
  150
• Based On ID
  Not Available
• Coin Description
  EcoBoost PHEV
• Coin Series
  Titanium [7 seat]
• Generation Mark
  3
• Insurance Group 1 - 50 Effective January 07
  16E
• Manufacturers Corrosion Perforation Guarantee - Years
  12
• Manufacturers Paintwork Guarantee - Years
  3
• NCAP Adult Occupant Protection %
  Not Available
• NCAP Child Occupant Protection %
  Not Available
• NCAP Overall Rating - Effective February 09
  Not Available
• NCAP Pedestrian Protection %
  Not Available
• NCAP Safety Assist %
  Not Available
• Did at least one aspect of this vehicle's safety give cause for concern?
  No
• Service Interval Frequency - Months
  24
• Service Interval Mileage
  20000
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  100000
• Standard manufacturers warranty - Years
  3
• Vehicle Homologation Class
  M1

Performance

• Engine Power - BHP
  150
• Engine Power - KW
  110
• Engine Power - RPM
  6500
• Engine Torque - LBS.FT
  258
• Engine Torque - MKG
  35.7
• Engine Torque - NM
  350
• Engine Torque - RPM
  4000

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  RDE 2

Tyres

• Alloys?
  Yes
• Space Saver?
  No
• Tyre Size Front
  215/55 R17
• Tyre Size Rear
  215/55 R17
• Tyre Size Spare
  TYRE REPAIR KIT
• Wheel Style
  Not Available
• Wheel Type
  17" ALLOY

Vehicle Dimensions

• Height
  1835
• Height (including roof rails)
  1856
• Length
  4853
• Wheelbase
  2970
• Width
  1855
• Width (including mirrors)
  2100

Weight and Capacities

• Fuel Tank Capacity (Litres)
  50
• Gross Vehicle Weight
  2560
• Luggage Capacity (Seats Down)
  3105
• Luggage Capacity (Seats Up)
  446
• Max. Loading Weight
  702
• Max. Towing Weight - Braked
  1400
• Max. Towing Weight - Unbraked
  750
• Minimum Kerbweight
  1858
• No. of Seats
  7
• Turning Circle - Kerb to Kerb
  12.1
