BMW 5 SERIES TOURING

Electric Vehicle Data

• Battery Capacity % guaranteed under warranty
  Not Available
• Battery Capacity in kWh
  22.1
• Battery Charging Scenario 1 - Charge Time (Mins)
  690
• Battery Charging Scenario 1 - Percentage Change
  0-100
• Battery Charging Scenario 1 - Power Supply - kW
  2.3
• Battery Charging Scenario 2 - Charge Time (Mins)
  195
• Battery Charging Scenario 2 - Percentage Change
  0-100
• Battery Charging Scenario 2 - Power Supply - kW
  7.4
• Battery Charging Scenario 3 - Charge Time (Mins)
  135
• Battery Charging Scenario 3 - Percentage Change
  0-100
• Battery Charging Scenario 3 - Power Supply - kW
  11
• Battery Charging Scenario 4 - Charge Time (Mins)
  Not Available
• Battery Charging Scenario 4 - Percentage Change
  Not Available
• Battery Charging Scenario 4 - Power Supply - kW
  Not Available
• Battery Leased
  No
• Battery Type
  Lithium-ion
• Charging Port Location
  Left Side Front
• Coupler/Connector Type
  Type 2
• Maximum Charging Rate - kW
  11
• NEDC Electricity Consumption kWh/100 km
  Not Available
• NEDC Maximum EV Range Miles
  Not Available
• Standard manufacturers Battery warranty - Mileage
  100000
• Standard manufacturers Battery warranty - Years
  8
• Usable Battery Capacity
  19.4
• WLTP - AER (km) - City
  103
• WLTP - AER (km) - Comb
  95
• WLTP - AER (miles) - City
  64
• WLTP - AER (miles) - Comb
  59
• WLTP - EC (kWh/100km) - City
  19.4
• WLTP - EC (kWh/100km) - Comb
  20.7
• WLTP - EC (kWh/100km) - Comb - TEH
  20.7
• WLTP - EC (kWh/100km) - Comb - TEL
  20.7
• WLTP - EC (kWh/100km) - Extra High
  24.9
• WLTP - EC (kWh/100km) - High
  18.8
• WLTP - EC (kWh/100km) - Low
  20.7
• WLTP - EC (kWh/100km) - Medium
  18.8
• WLTP - EC (miles/kWh) - City
  3.2
• WLTP - EC (miles/kWh) - Comb
  3
• WLTP - EC (miles/kWh) - Comb - TEH
  3
• WLTP - EC (miles/kWh) - Comb - TEL
  2.8
• WLTP - EC (miles/kWh) - Extra High
  2.5
• WLTP - EC (miles/kWh) - High
  3.3
• WLTP - EC (miles/kWh) - Low
  3
• WLTP - EC (miles/kWh) - Medium
  3.3
• WLTP - EC AC Ch Dep (kWh/100km) - Comb
  23
• WLTP - EC AC Ch Dep (miles/kWh) - Comb
  2.7
• WLTP - EC AC Weighted (kWh/100km) - Comb
  20.7
• WLTP - EC AC Weighted (kWh/100km) - Comb - TEH
  22.4
• WLTP - EC AC Weighted (kWh/100km) - Comb - TEL
  20.7
• WLTP - EC AC Weighted (miles/kWh) - Comb
  3
• WLTP - EC AC Weighted (miles/kWh) - Comb - TEH
  2.8
• WLTP - EC AC Weighted (miles/kWh) - Comb - TEL
  3
• WLTP - Equivalent AER (km) - City
  103
• WLTP - Equivalent AER (km) - Comb
  96
• WLTP - Equivalent AER (km) - Comb - TEH
  88
• WLTP - Equivalent AER (km) - Comb - TEL
  97
• WLTP - Equivalent AER (km) - Extra High
  81
• WLTP - Equivalent AER (km) - High
  107
• WLTP - Equivalent AER (km) - Low
  97
• WLTP - Equivalent AER (km) - Medium
  108
• WLTP - Equivalent AER (miles) - City
  64
• WLTP - Equivalent AER (miles) - Comb
  59.7
• WLTP - Equivalent AER (miles) - Comb - TEH
  54.7
• WLTP - Equivalent AER (miles) - Comb - TEL
  60.3
• WLTP - Equivalent AER (miles) - Extra High
  50.3
• WLTP - Equivalent AER (miles) - High
  66.5
• WLTP - Equivalent AER (miles) - Low
  60.3
• WLTP - Equivalent AER (miles) - Medium
  67.1

Emissions - ICE

• CO
  0.18
• CO2 (g/km)
  Not Available
• HC
  0.007
• HC+NOx
  Not Available
• Noise Level dB(A)
  65
• NOx
  0.005
• Particles
  0.0001
• Standard Emissions
  EURO 6

Emissions - PHEV

• WLTP - CO2 Ch Sus (g/km) - Comb
  160
• WLTP - CO2 Ch Sus (g/km) - Extra High
  161
• WLTP - CO2 Ch Sus (g/km) - High
  139
• WLTP - CO2 Ch Sus (g/km) - Low
  209
• WLTP - CO2 Ch Sus (g/km) - Medium
  159
• WLTP - CO2 Charge Depleting (g/km) - Comb
  5
• WLTP - CO2 Weighted (g/km) - Comb
  17
• WLTP - CO2 Weighted (g/km) - Comb - TEH
  20
• WLTP - CO2 Weighted (g/km) - Comb - TEL
  16

Engine and Drive Train

• Camshaft
  DOHC
• Catalytic Convertor
  Yes
• CC
  1998
• Compression Ratio
  11.6:1
• Cylinder Layout
  IN-LINE
• Cylinders
  4
• Cylinders - Bore (mm)
  82
• Cylinders - Stroke (mm)
  94.6
• Engine Code
  XB1141M2
• Engine Layout
  NORTH SOUTH
• Fuel Delivery
  TURBO INJECTION
• Gears
  8 SPEED
• Number of Valves
  16
• Transmission
  SEMI-AUTO

Fuel Consumption - ICE

• EC Directive 1999/100/EC Applies
  No

Fuel Consumption - PHEV

• WLTP - FC Ch Dep (l/100km) - Comb
  0.1
• WLTP - FC Ch Dep (mpg) - Comb
  2824.8
• WLTP - FC Ch Sus (l/100km) - Comb
  7.1
• WLTP - FC Ch Sus (l/100km) - Extra High
  7.1
• WLTP - FC Ch Sus (l/100km) - High
  6.2
• WLTP - FC Ch Sus (l/100km) - Low
  9.2
• WLTP - FC Ch Sus (l/100km) - Medium
  7
• WLTP - FC Ch Sus (mpg) - Comb
  39.8
• WLTP - FC Ch Sus (mpg) - Extra High
  39.8
• WLTP - FC Ch Sus (mpg) - High
  45.6
• WLTP - FC Ch Sus (mpg) - Low
  30.7
• WLTP - FC Ch Sus (mpg) - Medium
  40.4
• WLTP - FC Weighted (l/100km) - Comb
  0.7
• WLTP - FC Weighted (l/100km) - Comb - TEH
  0.9
• WLTP - FC Weighted (l/100km) - Comb - TEL
  0.7
• WLTP - FC Weighted (mpg) - Comb
  403.5
• WLTP - FC Weighted (mpg) - Comb - TEH
  313.9
• WLTP - FC Weighted (mpg) - Comb - TEL
  403.5

General

• AdBlue
  No
• Alternative Fuel Qualifying
  Yes
• Badge Engine CC
  2
• Badge Power
  299
• Based On ID
  Not Available
• Coin Description
  e
• Coin Series
  M Sport [Comfort+]
• Generation Mark
  8
• Insurance Group 1
  Not Available
• Insurance Group 1 - 50 Effective January 07
  40E
• Insurance Group 2
  Not Available
• Manufacturers Corrosion Perforation Guarantee - Years
  Not Available
• Manufacturers Paintwork Guarantee - Years
  Not Available
• NCAP Adult Occupant Protection %
  89
• NCAP Child Occupant Protection %
  85
• EURO NCAP Front and Side Impact test - Star Rating.
  Not Available
• NCAP Overall Rating - Effective February 09
  5
• EURO NCAP Pedestrian test - Star Rating.
  Not Available
• NCAP Pedestrian Protection %
  86
• NCAP Safety Assist %
  78
• Did at least one aspect of this vehicle's safety give cause for concern?
  No
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  Unlimited
• Standard manufacturers warranty - Years
  3
• Vehicle Homologation Class
  M1

Performance

• 0 to 62 mph (secs)
  6.4
• Engine Power - BHP
  299
• Engine Power - KW
  220
• Engine Power - RPM
  5000
• Engine Torque - LBS.FT
  332
• Engine Torque - MKG
  45.9
• Engine Torque - NM
  450
• Engine Torque - RPM
  1500
• Top Speed
  137

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  RDE 2

Tyres

• Alloys?
  Yes
• Space Saver?
  No
• Tyre Size Front
  245/45 R19
• Tyre Size Rear
  275/40 R19
• Tyre Size Spare
  TYRE REPAIR KIT
• Wheel Style
  DOUBLE SPOKE STYLE 935 M
• Wheel Type
  19" ALLOY

Vehicle Dimensions

• Height
  1515
• Height (including roof rails)
  Not Available
• Length
  5060
• Wheelbase
  2995
• Width
  1900
• Width (including mirrors)
  2156

Weight and Capacities

• Fuel Tank Capacity (Litres)
  60
• Gross Vehicle Weight
  2740
• Luggage Capacity (Seats Down)
  1700
• Luggage Capacity (Seats Up)
  570
• Max. Loading Weight
  675
• Max. Roof Load
  100
• Max. Towing Weight - Braked
  1800
• Max. Towing Weight - Unbraked
  750
• Minimum Kerbweight
  2065
• No. of Seats
  5
• Turning Circle - Kerb to Kerb
  11.7
